ROMAN BLINDS & ACCESSORIES
MADE-TO-MEASURE (MTM) ROMAN BLINDS
Image shown details all the elements that will be provided in a super lift Roman blind. There are options to select rods and chains.
· Profile with pre-attached hook tape.
· Child safe pulley housing to comply with BSEN13120 super lift
system of 1:4 ratio.
· Cord spools with cord guide and 300cms of 1.3mm lift cord.
· Choice of 8 metal bead chains - polished chrome, polished brass,
Order specification options:
Alternatively, blinds can be supplied without breakaway using either a 1:1 or a 1:4 sidewinder supplied with a wall mounted retainer.
Blind can be supplied with a universal smart click wall/ceiling bracket.
☑ Blind width (specify if measurement is recess size or actual blind width).
☑ Blind drop.
☑ Fitting height (to comply with BSEN13120 regulations).
☑ Left or right hand control.
☑ Chain colour.
☑ Chain drop. Unless specified, the chain will be 15cm less than the
blind drop so that it will still comply with BSEN13120 regulations. ☑ Rod and bottom bar preferences.
Our MTM blind consists of:
antique brass, antique silver, bronze, black nickel, satin nickel and stainless steel - made to your specific drop requirement. All made from brass or stainless steel, to prevent risk of rusting.
· Universal smart swivel wall/ ceiling bracket.
· Small white plastic eyelet rings 13mm diameter.
· 38mm sew on loop tape (to attach to face fabric).
· Cord clasps (RBCCS) to comply with BSEN13120 standards
regarding child safety.
· For your rods and bottom bars you have three options:
Technical specifications:
– Option one - Provided with fibreglass rods and white aluminium bottom bar (22mm x 4mm).
· Maximum width: 300cms.
· Maximum drop: 500cms.
· Maximum blind load weight:
– Option two - Provided with chrome plated steel rods and white aluminium bottom bar (22mm x 4mm).
– Super lift – 7kg - 1:4 (if you pull the chain 20cm it will rise 5cm).
– Option three - Provided with neither rods nor bottom bar- for you to use your own.
– 1 rod is provided for each 30cm of drop. · Easy step by step fitting instructions.
CORD SPOOLS AND BRACKETS
Made-to-measure length No. of cord spools
No. of brackets
50-75cm
2
2
75-100cm
3
2
100-125cm
4
3
125-150cm
4
3
150-175cm
5
4
175-200cm
5
4
200-225cm
6
5
225-250cm
6
5
250-275cm
7
6
275-300cm
7
6
sales@hunterandhyland.co.uk www.hunterandhyland.co.uk page 3 Workroom & Supplies
